Technical specifications of the remote control

  • Total 12 channels, 8 of them switchable:                                                                                                        4 channels are proportional adjustable with the steering lever as well as the gas and brake lever, the knob and 2 up and down switches. 8 more channels are switchable on and off with some function-buttons on the top of the remote control.
  • 2 switchable channels are determined as indicators:                                                                                                     With the function switches on the left and on the right on the top of the remote control it's able to activate the indicator left and right. The indicators are turned off with the center position of the steering.
  • 8 model memories:                                                                                                                                            It's able to select between 8 different models which can be named individual with 8 digits or letters.
  • 3 setups each:                                                                                                                                                          It's able to select between 3 different setups for each model, for example for dryness and wetness or for professionals and beginners.
  • Ball-bearing levers with hall sensors:                                                                                                         The steering lever as well as the gas and brake lever are ball-bearing and have a contactless signaling with hall sensors.
  • Easy menu navigation with the levers:                                                                                                                   As soon as the menu is opened, the steering lever and gas and brake lever are for a simple intuitive operation of the menu and the selectable settings.
  • ABS function:                                                                                                                                                   It's possible to activate an ABS regulation for the break the break of a model. It is switched between the "braking phase" and the "rolling phase" for this. The times of the phases are adjustable independently from each other. As well it is possible to select up to 3 channels for the brake to create different retardment on the front and the rear axle, especially for nitro models.
  • Channel mix for chain drive:                                                                                                                               A default configuration mixes the steering and the gas-brake channel so that it is possible to control a chain vehicle easily with 2 speed controllers and without another devices.
  • All wheel steering:                                                                                                                                                      It's possible to synchronize the steering channel1 to the channel3. The knob controls a parallel or antiparallel steering for the rear axle yet.
  • Telemetry:                                                                                                                                                     You can see the battery status of the model permanent on the remote control and set an acustic and visual warning if the charge level is to low. Furthermore it's possible to connect up to 6 sensors on the receiver whose data are shown on the remote control.
  • Stopwatch with countdown function:                                                                                                                     With the stop watch it's possible to stop and save the total time and the lap time on up to 8 different selectable and adjustable tracks. You can also set a countdown which triggers an acoustic signal if it's on 0.

          Frequencies: 2,4Ghz to transmit the control signals, 5,8Ghz to receive the video and audio signal
          Max. transmission power: 20dBm at 2,4Ghz
          Range (open area): About 1000m for the 2,4Ghz control signal, About 200m for the 5,8Ghz A/V signal
          Video format: NTSC/PAL
          Length: 171mm
          Width: 130mm
          Height: 22mm ohne Hebel, 42mm mit Hebel
          Battery runtime: About 2h
